SONY KDE50XS955
Instrukcja Serwisowa

General
Problem Possible Remedies

How to reset TV to factory settings

s

How to restore Video settings to s factory settings How to restore Audio settings to s factory settings Cannot cycle through the other s video equipment connected to the TV Cannot operate Menu s Lost password s

Turn on the TV. While holding down the RESET button on the remote control, press the POWER button on the right side of the TV. (The TV will turn itself off, then back on again.) Release the RESET button. Press the RESET button on the remote control while in the Video Menu (see page 92). Press the RESET button on the remote control while in the Audio Menu (see page 95). Be sure the Label Video Inputs option is not set to Skip (see page 105).

TIMER LED on front panel is lit s

Digital cable box does not work s

Cannot record digital channels s to VCR

If a Menu option appears in gray, this indicates that the TV is in a state in which the Menu option is not available. In the password screen (see page 101), enter the following master password: 4357. The master password clears your previous password; it cannot be used to temporarily unblock channels. The LED (see page 16) blinks when the TV is turned on, then shuts off when the picture is displayed. If the LED blinks continuously, this may indicate the TV needs service. When lit, indicates that the timer is set (page 107). When the timer is set, this LED will remain lit even when the TV is turned off. If you are connecting a VCR and digital cable box using a splitter, as described on page 32, you must use a special bi-directional splitter that is designed to work with your digital cable box. Contact your cable TV company for details. Only analog channels can be recorded to your VCR.

KDE-50XS955 (UC)

2-6E
