Audio Receiver
For improved sound quality, you may want to play the TV�s audio through your stereo system.
To connect an audio system
1 Use an audio cable to connect the TV�s audio output jacks to the audio
receiver�s line input jacks.
Rear of TV
Setup
VIDEO IN
1
Receiver
3
R -AUDIO- L
(MONO)
VIDEO
S VIDEO
R -AUDIO- L AUDIO OUT (VAR/FIX)
WOOFER OUT (VAR)
To line input
Audio cable
2 Using the TV�s Audio Menu, set the Speaker option to Off. Then set
the Audio Out option to Fixed or Variable, depending on how you want to control the volume. For details, see �Using the Audio Menu� on page 86.
3 Turn on the audio receiver, and then set the receiver�s line input to the
jack into which you connected the TV.
