SECTION 1 GENERAL
Getting Started

Welcome! Precautions

� If you turn on the monitor immediately after power has been restored at an interruption, an LCD burn may occur. This is not a malfunction. The image will become normal after a certain time. On blanking around the pciture The monitor displays black masks between the picture and the screen vessel because the monitor under-scans to obtain the necessary space on the screen to display the picture. This is called blanking. Note that the black masks on each vessel are not uniform. The blanking on the video picture will be wider to optimize picture.
Blanking

Step 1: Installing the projection monitor

This projection monitor operates on extremely high voltage. To prevent fire or electric shock, please follow the precautions below. On safety � Operate the monitor only on 100 V to 120 V AC. � One blade of the plug is wider than the other for safety purposes and will fit into the power outlet only one way. If you are unable to insert the plug fully into the outlet, contact your dealer. � Should any liquid or solid object fall into the cabinet, unplug the monitor and have it checked by qualified personnel before operating it further. � Unplug the monitor from the wall outlet if you are not going to use it for several days or more. To disconnect the cord, pull it out by the plug. Never pull the cord itself. � The fans inside the monitor continue working for a while even after the monitor has been turned off. Do not unplug the monitor from the AC outlet while the fans are working. On installation � To prevent internal heat build-up, do not block the ventilation openings. � Do not install the monitor in a hot or humid place, or in a place subject to excessive dust or mechanical vibration. On screen The screen surface is easily scratched. Do not rub, touch or tap it with sharp or abrasive objects. Be especially careful when transporting the monitor. On LCD panel � Do not expose the screen to direct sunlight. It may damage the LCD panel. � When the monitor is used in a cold place, the image may look lengthened. This is not a malfunction. The image will become normal when the temperature rises. � When the same static picture has been displayed continuously, an afterimage impression of that picture may remain on the screen. This will disappear after a certain time.

Optimum viewing area
For the best picture quality, install the monitor within the areas shown below.


p for KL-W7000

Vertical viewing area (side view)

p for KL-W9000

Vertical viewing area (side view)

Screen vessel

On moisture condensation If the projection monitor is transported directly from a cold to a warm location, or if the room temperature has changed suddenly, the picture may be blurred or show poor color. This is because moisture has condensed on the lenses inside. If this happens, let the moisture evaporate before using the monitor.

EN
30° 35° 30° 35°

� 5 �

On cleaning � Clean the cabinet of the monitor with a dry soft cloth. Stubborn stains may be removed with a cloth slightly dampened with solution of mild soap and water, then wipe it with a dry soft cloth. Do not use any type of solvent such as alcohol, benzine, thinner or insecticide. Such solvent may damage the finish of the monitor or erase the indications on the panel. � Wipe the screen with a dust remover (supplied) occasionally, as the screen easily catches dust. The dust remover is washable. Wash it with warm water or mild detergent solution. � Stubborn stains on the screen may be removed with a soft cloth slightly dampened with solution of mild soap and water. � If the picture becomes dark after using the monitor for a long period of time, it may be necessary to clean the inside of the monitor. Consult qualified service personnel.
1.5 m 2m

Horizontal viewing area (top view)

Horizontal viewing area (top view)

75°

75°

75°

75°

1.5 m

2m
