72-Channel mono configuration
In this configuration you can connect 2 speakers (such as 2 subwoofers) to the KMF-X9000 and send a single preamp signal (such as a mono subwoofer output) to both speakers without using a Y-adapter. The amplifier delivers its rated stereo power output to each speaker.
1 Make sure that the KMF-X9000�s power cord is unplugged from the wall outlet before making any connections. 2 According to the speakers to be used, set the speaker impedance selector switch as follows:
� For 2 � speakers: Set the 2� (STEREO)/6� OVER switch to 2� (STEREO) and 6� OVER/2� switch to 2�. � For 6-16 � speakers: Set the 2� (STEREO)/6� OVER switch to 6� OVER and 6� OVER/2� switch to 6� OVER.
3 Connect the amplifier as shown in the diagram.
� Make sure to connect the audio input cable to the MONO/BTL input.
KRF-X9995D
When a monaural preout signal is to be connected, be sure to connect it to the MONO/BTL terminal.
Audio cord (not supplied)
Stereo mini-plug cord (supplied) For 12 V RELAY CONTROL, see below.
* In the case of 2 �
In the case of 6 �
To wall AC outlet
Subwoofers (2�-16�) (Right) (Left)
* If you connect more than one pair of speakers to the KMF-X9000, move the 2� (STEREO)/6� OVER (THX) switch to the 2� (STEREO) position. The amplifier�s performance is not THX®-certified when the switch is set in the 2� (STEREO) position.
Now you can plug the power cord of this unit into the AC outlet!
CAUTION:
Before reconnecting a speaker cord or switching a selector switch, turn OFF the power and unplug the power cord to avoid malfunctions or damage to the unit.
712 V Relay power control
The KMF-X9000 can be powered on and off by a 12 volt trigger signal from a compatible component (such as the Kenwood KRF-X9995D receiver).
1 Make sure that the KMF-X9000�s power cord is unplugged from the wall outlet before making any connections. 2 Connect the supplied mini cable to the KMF-X9000�s RELAY CONTROL input and the 12 V relay control output of the
KRF-X9995D or other compatible component. � When the KMF-X9000�s POWER switch is turned ON, the amplifier will remain in the STANDBY mode (the STANDBY indicator will be lit) as long as there is no signal at the RELAY CONTROL input. � The KMF-X9000 will automatically turn ON when a 12 V signal is applied to the RELAY CONTROL input. � When the 12 V signal is removed from the KMF-X9000�s RELAY CONTROL input, the amplifier will go back into the STANDBY mode. � If there is no cable connected to the KMF-X9000�s RELAY CONTROL input, the amplifier�s STANDBY indicator will not function, and its ON/OFF status will be controlled by the POWER switch.
