7. Select �GRN SKEW�, and correct the tilt of horizontal lines and vertical lines. GRN SKEW (Horizontally/Vertically)
Push the joystick to Push the joystick to
10. Select �GRN MSIZ�, and correct the space intervals for the horizontal section so the screen is equal. GRN MSIZ (Horizontally)
Push the joystick to
Push the joystick to
11. Select �GRN MLIN�, and correct the sizes of the horizontal line so the center of the screen is symmetrical left and right.
Push the joystick to Push the joystick to
GRN MLIN (Horizontally)
8. Select �GRN SIZE�, and adjust so that each distance from center to left end and to right end is equal. Adjust so that each distance from center to top and to bottom is equal. GRN SIZE (Horizontally/Vertically)
Push the joystick to Push the joystick to
Push the joystick to
Push the joystick to
Note: The SIZE and LIN, MSIZ and MLIN adjustments affect each other. If necessary, adjust these mutually. 12. Select �GRN PIN�, and adjust so that right and left vertical lines on the screen become straight. Adjust so that upper and lower horizontal lines on the screen become straight. GRN PIN (Horizontally/Vertically)
Push the joystick to Push the joystick to
Push the joystick to
Push the joystick to
9. Select �GRN LIN�, and adjust so that each space at the right end and at the left end of screen is equal. Adjust so that each space at the top and at the bottom of screen is equal. GRN LIN (Horizontally/Vertically)
Push the joystick to Push the joystick to Push the joystick to Push the joystick to
13. Select �GRN KEY�, and adjust so that upper and lower horizontal lines on the screen become parallel. GRN KEY (Vertically)
Push the joystick to
Push the joystick to
Push the joystick to
Push the joystick to
Note: The VPIN and KEY adjustments affect each other. If necessary, adjust these mutually. 14. Press the �9� button on the remote commander to enter �ne adjustment mode.
