KRC-335/365/465/465W/565
SPECIFICATIONS
q KRC-335 FM Section
Frequency Range .............................. 87.9MHz-107.9MHz (Frequency Step) (200kHz) Channel Space Selection .................. 50k/200kHz Usable Sensitivity(S/N:30dB) ............ 9.3dBf(0.8µV/75�) Quieting Sensitivity(S/N:50dB) .......... 15.2dBf(1.6µV/75�) Frequency Response(±3.0dB) .......... 30Hz-15kHz S/N .................................................... 70dB(MONO) Selectivity .......................................... 80dB(±400kHz) Stereo Separation ............................. 40dB(1kHz)
q KRC-365/565/465/465W FM Section
Frequency Range .............................. 87.5MHz-108.0MHz (Frequency Step) (50kHz) Frequency Range .............................. 87.9MHz-107.9MHz (Frequency Step) (200kHz) Channel Space Selection .................. 50k/200kHz Usable Sensitivity(S/N:30dB) ............ 9.3dBf(0.8µV/75�) Quieting Sensitivity(S/N:50dB) .......... 15.2dBf(1.6µV/75�) Frequency Response(±3.0dB) .......... 30Hz-15kHz S/N .................................................... 70dB(MONO) Selectivity .......................................... 80dB(±400kHz) Stereo Separation ............................. 40dB(1kHz)
AM Section
Frequency Range .............................. 530kHz-1700kHz (Frequency Step) (10kHz) Channel Space Selection .................. 9k/10kHz Usable Sensitivity(S/N:20dB) ............ 28dB µ(25µV)
AM Section
Frequency Range .............................. 531kHz-1611kHz (Frequency Step) (9kHz) Frequency Range .............................. 530kHz-1700kHz (Frequency Step) (10kHz) Channel Space Selection .................. 9k/10kHz Usable Sensitivity(S/N:20dB) ............ 28dB µ(25µV)
CASSETTE Section
Tape Speed ....................................... 4.76cm/sec. Wow/Flutter(wrms) ............................ 0.08%(WRMS) Frequency Response(±3.0dB) .......... 30-18kHz(70µs) Separation ......................................... 43dB(1kHz) S/N(dB) Dolby NR off ........................ 57dB Dolby BNR on ................................... 65dB
CASSETTE Section
Tape Speed ....................................... 4.76cm/sec. Wow/Flutter(wrms) ............................ 0.08%(WRMS) Frequency Response(±3.0dB) .......... 30-14kHz(120µs) Separation ......................................... 43dB(1kHz) S/N(dB) Dolby NR off ........................ 57dB
AMPLIFIER Section
Preout Level/Load ............................. 1800mV/10k� Preout Impedance ............................. 600� Maximum Power ............................... 45W�4 Full Bandwidth Power ....................... 22W�4 (at less than 1%THD)
AMPLIFIER Section
Preout Level/Load ............................. 1800mV/10k� Preout Impedance ............................. 600� Maximum Power ............................... 45W�4 Full Bandwidth Power ....................... 22W�4 (at less than 1%THD)
General
Operating Voltage ............................. 14.4V (11V-16V allowable) Current Consumption ........................ 10A Installation Size (W) .......................... 182mm(7-3/16in) (H) .......................... 53mm(2-1/16in) (D) .......................... 152mm(6in) Weight ............................................... 1.3kg(2.9lbs)
General
Operating Voltage ............................. 14.4V (11V-16V allowable) Current Consumption ........................ 10A Installation Size (W) .......................... 182mm (H) .......................... 53mm (D) .......................... 152mm Weight ............................................... 1.3kg
KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice. US and foreign patents licensed from Dolby Laboratories Licensing Corporation.
