Chapter Two : Setting Up PowerTouch 3. Touch on the Setup menu to access the Preference menu. 6. Touch sets: to open the list of available jack
Audio-Video Receiver KRF-X9992D 10. Touch . This instructs PowerTouch to send a �power� test signal to the receiver. If your device turns on, the code you entered was correct. If it does not turn on, try the next code in the list. Continue until one of the codes works. If none of the codes work, see �What if my device does not work with any of the codes on the list?� on page 39. If you enter the code preceded by �Sys-� or �System� on step 9, skip this step. 11. When you have a code that works, touch Check off that device on your list. Repeat steps 5 through 11 until you are finished identifying devices to PowerTouch. When you are done, turn to �How Do I Operate Devices?� on page 26 in the Users� Guide and note which icon corresponds to which connected device. .
� TV1 and TV2 (these allow PowerTouch to control your TV or cable tuner, even if it isn�t connected to one of the receiver�s input jack sets). � VIDEO1 through VIDEO4 � � CD1 MD/TAPE1 CD2/TAPE2
Remote Setup
�
Note that Phono and AV AUX (the additional camcorder/VCR jack set on the front of the receiver) do not need to be configured here. Touch the jack name on the list. 7. Touch to select the type of device you have connected to the jack set. 8. Touch to select the device�s brand.
38
4. Touch on the Preference menu to access the IR Setup menu.
9. Touch . You can now choose from a list of all the codes available for the device. Touch the first code on the list. � If the devices are connected with a system control cable, be sure to select the code preceded by �Sys-� or �System�. This instructs PowerTouch to send all commands for the device to the receiver, which will control the device via the system control cable. � If you have a Kenwood Dual-Play 200-Disc CD Changer, you will need to set both CD1 and CD2/ TAPE2 to the correct code for this device (�Sys- Mega�).
5. Refer to �Noting Your Devices� on page 3 where you noted which device was connected to which jack set.
