KV-G14K3/G21K3

2-6. PICTURE TUBE REMOVAL
(1) For KV-G14K3

a
3 C board 2 A board

b b

RM-870

a
4 Deflection yoke 5 Four screws (Tapping screws)
1 Turn up one side of the rubber cap in the direction indicated by the arrow a. 2 Using a thumb pull up the rubber cap firmly in the direction indicated by the arrow b.

1 Anode cap

c

Cushion

� 12 �
(2) For KV-G21K3

Anode button
3 When one side of the rubber cap is separated from the anode button, the anode-cap can be removed by turning up the rubber cap and pulling it up in the direction of the arrow c.

3 C board 4 Deflection yoke 2 A board 5 Four screws (Tapping screws)

�

HOW TO HANDLE AN ANODE-CAP

1 Anode cap

1 Do not damage the surface of anode-caps with sharp shaped objects. 2 Do not press the rubber too hard so as not to damage the inside of anode-caps. A metal fitting called the shatter-hook terminal is built into the rubber. 3 Do not turn the foot of rubber over too hard. The shatter-hook terminal will stick out or damage the rubber.

Cushion
