SONY MDRCD780
Instrukcja Serwisowa

� EXPLODED VIEWS
NOTE: � The mechanical parts with no reference number in the exploded views are not supplied. � Items marked �*� are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.

2 6

1

15

16 3 18 3 19 17 13 12 9 7 13 5 13 11 10 20 20 4

14

8 7
MDR-CD480
Ref. No. 1 2 3 4 5 5 5 5 5 5 6 6 6 6 7 8 8 8 8 8 8 9 10 10 11 12 12 Part No. X-3379-039-1 X-3379-040-1 7-621-772-10 X-3379-212-1 3-045-258-01 3-046-466-01 3-046-843-01 3-046-844-01 3-046-845-01 3-046-846-01 3-045-273-01 3-045-273-11 3-045-274-01 3-045-274-11 7-685-133-19 X-3379-041-1 X-3379-042-1 X-3379-043-1 X-3379-044-1 X-3379-207-1 X-3379-208-1 1-794-152-11 1-542-429-11 1-542-434-11 7-682-247-09 Description BAND (F) ASSY, HEAD BAND (R) ASSY, HEAD SCREW +P 2X4 SUSPENDER ASSY PAD, EAR (L)(CD780) PAD (R), EAR (CD780) PAD (L), EAR (CD580) PAD (R), EAR (CD580) PAD (L), EAR (CD480) PAD (R), EAR (CD480) HOLDER (L) (CD780) HOLDER (L) (CD480/CD580) HOLDER (R) (CD780) HOLDER (R) (CD480/CD580) SCREW +P 2.6X6 TYPE2 NON-SLIT PLATE (L) ASSY, FRONT (CD780) PLATE (R) ASSY, FRONT (CD780) PLATE (L) ASSY, FRONT (CD580) PLATE (R) ASSY, FRONT (CD580) PLATE (L) ASSY, FRONT (CD480) PLATE (R) ASSY, FRONT (CD480) JACK (SMALL TYPE) DRIVER (040F018) DRIVER (050F027) SCREW +K 3X6 Remark Ref. No. 13 14 14 14 14 14 14 15 15 16 17 18 18 18 18

5
MDR-CD580/CD780
Part No. 3-045-281-01 3-045-283-01 3-045-284-01 3-045-287-01 3-045-288-01 X-3378-829-1 X-3378-830-1 1-792-447-11 1-792-448-11 1-506-589-11 7-685-104-19 3-045-275-01 3-045-275-11 3-045-276-01 3-045-276-11 Description WHEEL HOUSING (L) (CD580) HOUSING (R) (CD580) HOUSING (L) (CD480) HOUSING (R) (CD480) HOUSING (L) ASSY (CD780) HOUSING (R) ASSY (CD780) CORD (WITH PLUG) (CD780) CORD (WITH PLUG) (CD480/CD580) PLUG, ADAPTOR SCREW +P 2X6 TYPE2 NON-SLIT LID (L), HOLDER (CD780) LID (L), HOLDER (CD480/CD580) LID (R), HOLDER (CD780) LID (R), HOLDER (CD480/CD580) Remark

19 3-045-269-01 CHASSIS (L) 19 3-045-270-01 CHASSIS (R) 20 3-318-203-62 SCREW (B1.7X4), TAPPING ************************************************************* ACCESSORIES & PACKING MATERIALS ******************************** 3-045-851-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH,GERMAN,SPANISH,ITALIAN, PORTUGUESE,RUSSIAN) (CD580/CD780)

3-045-271-01 HANGER (L) 3-045-272-01 HANGER (R)

Sony Corporation
9-927-662-11
Personal Audio Division Company

�2�

2000B0481-1 Printed in Japan ©2000. 2 Published by General Engineering Dept.
