SONY MHCGSX100W
Instrukcja Serwisowa

MHC-GSX100W
SERVICE MANUAL
Ver 1.0 2003. 03
� MHC-GSX100W is composed of following models. As for the service manual, it is issued for each component model, then, please refer to it.

US Model Canadian Model

COMPONENT MODEL NAME FOR MHC-GSX100W
MHC-GSX100W COMPACT DISC DECK RECEIVER SYSTEM SPEAKER SYSTEM HCD-GSX100W SS-GSX100

SPECIFICATIONS
General Power requirements: Power consumption: 120 V AC, 60 Hz 170 W

PARTS LIST
Part No. Description ACCESSORIES Remark

***********
1-477-800-11 COMMANDER, STANDARD (RM-SX100W) 0 1-477-801-11 1-501-659-72 1-559-906-32 1-754-102-22 4-228-953-01 4-245-586-11 4-245-586-21 A-4736-996-A ADAPTOR, AC (AC-GSX100) (For TMR-GSX100) ANTENNA (FM) CORD, CONNECTION (PHONO to STEREO MINI PLUG) ANTENNA, ROOP (LW.MW) COVER, BATTERY (For RM-SX100W) INSTRUCTION MANUAL (ENGLISH) INSTRUCTION MANUAL (FRENCH) (Canadian) TRANSMITTER (TMR-GSX100)

Dimensions (w/h/d) incl. projecting parts and controls Amplifier/Tuner/Tape/CD section: Approx. 280 x 326 x 490 mm Speakers: Transmitter: Mass: Speakers: Transmitter: Supplied accessories: Approx. 255 x 326 x 310 mm Approx. 136 x 100 x 103 mm Approx. 11.5 kg Approx. 4.6 kg net per speaker Approx. 146 g Remote (1) size AA (R6) batteries (2) AM loop antenna (1) FM lead antenna (1) Transmitter (1) AC adaptor (1) Connecting cord phono plug-stereo miniplug (1m) (1) Design and specifications are subject to change without notice.

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié.

MiNi Hi-Fi COMPONENT SYSTEM
9-877-218-01
2003C0200-1 © 2003.03

Sony Corporation
Home Audio Company Published by Sony Engineering Corporation
