SONY MHCRXD3
Instrukcja Obsługi

DHC-MDX10
SERVICE MANUAL
US Model Canadian Model AEP Model UK Model E Model Australian Model
�Abbreviation CND : Canadian model G : German model SP : Singapore model MY : Malaysia model HK : Hong Kong model AR : Argentine model KR : Korea model AUS : Australian model

� DHC-MDX10 is composed of following models. As for the service manual, it is issued for each component model, then, please refer to it.

COMPONENT MODEL NAME FOR DHC-MDX10 COMPACT DISC DECK RECEIVER SYSTEM FRONT SPEAKER SYSTEM HCD-MDX10 SS-MDX10

SPECIFICATIONS
General Power requirements North American models: European models: Australian models: Mexidan models: Other models: 120 V AC, 60 Hz 230 V AC, 50/60 Hz 240 V AC, 50/60 Hz 120 V AC, 50/60 Hz 110 - 120 V or 220 - 240 V AC, 50/60 Hz

PARTS LIST
Ref.No. Part No. Description Remark ACCESSORIES & PACKING MATERIALS ******************************** 1-418-251-11 1-501-374-51 1-501-594-31 1-501-659-41 1-769-317-11 3-866-529-11 3-866-529-21 3-866-529-31 REMOTE COMMANDER(RM-MDX10) ANTENNA,LOOP ANTENNA(FM)(AEP,UK,G,CIS) ANTENNA(FM)(US,CND,E,SP,MY,HK,AR,KR,AUS) CORD,SPEAKER(2.5m) MANUAL,INSTRUCTION(ENGLISH)(EXCEPT G) MANUAL,INSTRUCTION (FRENCH)(CND,AEP,E,SP,MY,HK) MANUAL,INSTRUCTION (SPANISH)(AEP,E,SP,MY,HK,AR) MANUAL,INSTRUCTION(GERMAN)(AEP,G) MANUAL,INSTRUCTION (DUTCH,ITALIAN,PORTUGUESE)(AEP) MANUAL,INSTRUCTION (DANISH,FINNISH,SWEDISH)(AEP) MANUAL,INSTRUCTION(CHINESE)(SP,MY,HK) MANUAL,INSTRUCTION(KOREAN)(KR) MANUAL,INSTRUCTION(POLISH,RUSSIAN)(CIS) MANUAL,INSTRUCTION(CZECH)(CIS) MANUAL,INSTRUCTION(GREEK)(CIS) MANUAL,INSTRUCTION(HUNGARIAN)(CIS) MANUAL,INSTRUCTION(TURKISH)(CIS) CUSHION(FOOT) (SS-MDX10) COVER,BATTERY(FOR RM-MDX10)

Power consumption U.S.A. models: Canadian model: European models: Other models:

115 watts 95 watts 165 watts 170 watts

Design and specifications are subject to change without notice. Supplied accessories AM loop antenna (1) Remote Commander (1) Batteries (2) FM lead antenna (1) MD connecting cord (1) Front speaker pads (8) Speaker cords (2) Design and specifications are subject to change without notice. 3-866-529-61 3-866-529-71 3-866-529-81 3-866-578-11 3-866-578-21 3-866-578-31 3-866-578-41 3-866-578-51 4-210-254-01 4-991-151-01 3-866-529-41 3-866-529-51

MINI Hi-Fi COMPONENT SYSTEM

MICROFILM

Sony Corporation
9-928-908-11
Home Audio Company

99D001689-1 Printed in Japan ©1999.4 Published by Quality Assurance Dept.
