SONY MZB100
Instrukcja Serwisowa

MZ-B100

3-6. OPTICAL PICK-UP BLOCK (LCX-4R)

2 gear (SA) 1 washer (0.8-2.5)

5 screw (M1.4)

6 spring, thrust detent 3 screw (M1.4) 8 Pull off �screw, lead� 4 spring, rack

7

9 Opening the over write head toward the direction A, remove the optical pick-up block (LCX-4R) toward the direction B. B

Note: Do not open the entire assy forcibly, when opening the over write head.

Optical pick-up block (LCX-4R)
A

over write head section

9
