24
Let�s have sound
Basic operation
PHONES
Listening through headphones (optional)
Insert the headphone plug into the PHONES jack.
Reproducing sound with enhanced bass (EX.BASS) (NV-301 only)
÷ The sound from all speakers is cut off.
3 1 2
NV-301 NV-701
Muting the sound temporarily (MUTE)
Basic section
STANDBY
STANDBY
1. Switching the power ON (OFF)
When the power is ON, pressing the ON/STANDBY (POWER) key puts the unit in the standby mode and the STANDBY indicator lights up.
POWER
ON/STANDBY
1
2. Selecting the desired output
(For U.S.A.)
CD
CD
TUNER
BAND
TUNER
BAND
Select the desired source by pressing the CD, TUNER, TAPE, MD/DVD (NV301 only), or VIDEO/6ch IN (NV-701 only) key.
TAPE
TAPE
2
MD/DVD
VIDEO/6ch IN
NV-301
VO L
UME CONTR OL
NV-701
÷ When you press the TAPE or CD key, the unit starts playback automatically (if a tape or CD has been loaded beforehand). ÷ If you select the MD/DVD (NV-301 only), or VIDEO/6ch IN (NV-701 only) external input mode, also read the instruction manual of the component connected to the MD/DVD (NV-301 only) jacks or VIDEO jacks (NV-701 only). ÷ (NV-701 only) Pressing the VIDEO/6ch IN key repeatedly switches the input between the components connected to the VIDEO 1 and VIDEO 2 jacks.
3. Volume adjustment
÷ The display shows a reference value.
