2-3. How to Start the Diagnostics
Precaution: The supplied floppy disk containing the diagnostics program can be damaged because it will be written the Log and used as FDD read-write test. Be sure to make a backup of the diagnostics floppy disk and use a backup disk for diagnostics.
Starting up the diagnostics
� � � Specify the FDD as the startup drive so that the system boots up from the diagnostics FD. Insert the diagnostics CD-ROM media into the DVD-ROM bay. Insert the diagnostics FD into the FDD bay. Turn off the main power of the system once and back on to boot up the system from the diagnostics FD. The FDD bay is normally connected to the parallel port while the DVD-ROM bay is installed in the multi-purpose bay. However, use of the docking station is required so that the CD-ROM is installed in the multi-purpose bay of the docking station depending on some contents of the test. � When the system is booted from the diagnostics floppy disk, the start menu appears. Select a desired item to execute the diagnostics. When PASS is displayed as the result of diagnostics, the test is ended without any errors. When FAIL is displayed as the result of diagnostics, the test is ended with some errors.
2-4. Test Items
The test items are shown below.
2-4-1. Start Menu
1: Diagnostics for PCG-838 Select the respective test items of the PCG-838 Diagnostics from the menu and perform the selected test. 2: PASSWORD BYPASS The password which bypasses the PASSWORD is created. 3: Quit START MENU Exits the diagnostics.
2-4-2. PCG-838 Diagnostics
List of Test Items The test items which are performed one after another or by selecting a specific item, are listed as follows. (Short descriptions of the respective test items follow later.) 1. Machine configuration 2. Check system bios revision 3. Check configuration 4. Audio test group (1) Audio test (ALL) (2) Audio test (CD-DA test) (3) Audio test (Speaker test) (4) Audio test (Use JIG) (5) Remote controller button test 5. Battery test group (1) Battery 1 test
PCG-838 (UC) 2-4
|
|
|
> |
|
