SONY PCGACD5
Instrukcja Serwisowa

PCGA-CD5
SERVICE MANUAL
US Model Canadian Model
Illust : PCGA-CD5

SPECIFICATIONS
Disc
Compatible discs � CD-ROM (mode-1 or mode-2, form 1) � CD-ROM XA (mode-2, form 2) � Photo CD (multisession) � CD-DA � CD-R � CD-I � Video CD � CD Extra (CD+) Disc diameter: 12 cm (4 3/4 in.), 8 cm (3 in.)

PCGA-PC5 interface card Interface: Conforms to PCMCIA 2, 1/JEIDA 4.2 Card type: PCMCIA Type II Power: 5V DC, approx. 80 mA Card dimensions: 2 1/4 � 7/32 � 3 3/8 inches (54 � 5 � 85.6 mm) (w/h/d) Mass: Approx. 1 oz. (28 g) Design and specifications are subject to change without notice.

Drive performance
1)

The maximum data transfer rate varies with the computer�s performance.

Data transfer rate 1) 2.1Mbps (14� speed) 0.6Mbps (8-cm CD) Access time Average (1/3 stroke): 150 ms

ACCESSORY & PACKING GROUP ************************* Ref No. Part No. 101 102 9-881-754-01 9-881-752-01 9-881-753-01 Description ADAPTER, AC CARD, PC MANUAL, INSTRUCTION

Environmental conditions/Storage conditions
Operating temperature �41°F to 104°F (5°C to 40°C) Operating humidity 20% to 80%RH (noncondensing) Storage environment Temperature: �4°F to 131°F (�20°C to 55°C) Humidity: 15% to 90%RH (noncondensing)

Power requirements and physical conditions
Power Power supply jack: 6V (rated power) The CD-ROM drive draws DC power from 120V � 240V AC power supply through the (supplied) AC adapter. Power consumption Approx. 8 W (CD-ROM playback mode) Approx. 1 W (standby (power off) mode) Dimensions Approx. 5 1/4 � 29/32 � 6 inches (132 � 23 � 152 mm) (w/h/d) Mass Approx. 14 oz. (395 g) (drive only) on

101 AC adapter

102 PC card

Interface
Supported interface ATAPI compatible MPC standards MPC1 and MPC2 Buffer size 128 KB

This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation.

CD-ROM Drive
Sony Corporation
English 2001B1100-1 © 2001 Sony Corporation PNC Planning & Control Dept. [SODP]

Printed in USA

9-872-196-11

Information Technology Company

�1�
