SONY PCGF590
Instrukcja Serwisowa

PCG-F590
SERVICE MANUAL
US Model Canadian Model
Basic performances of PCG-F590 are the same as those of PCG-F580. Therefore, this manual describes the differences from PCG-F580. Refer to the following manual that is already issued for repair and inspection.

PCG-F540/F560/F570/F580 SERVICE MANUAL (9-872-077-11)

MAJOR DIFFERENCES OF SPECIFICATIONS
CPU

Items

o C
64MB 12GB

Standard RAM HDD

Mobile PentiumRIII 650MHz

n

id f

en
128MB 18GB

t

l ia
PCG-F590

PCG-F580

Mobile PentiumRIII 750MHz

MAJOR DIFFERENCES OF PARTS LIST
Page*1 PCG-F580 Ref.No. Part No. Description 24 1-772-357-11 (F580)...HDD (12.0GB)
5-2

PCG-F590 Description HDD (18.1GB) HARD DISK (18.1GB-MHJ2181AT) IC KMM464S1724BT1-FL (PC 100 SO-DIMM 128MB) 8-759-665-57 IC HYM71V65M1601LTX-10S (PC 100 SO-DIMM 128MB) A-8066-115-A COMPLETE PWB MBX-30 (P750) ASSY (S) 4-648-068-11 LABEL ID (UC) Part No. 1-772-387-11 1-772-718-11 8-759-665-37

81 81 88

8-759-638-65 IC HYM7V65801BLTQG-10S (PC 100 SO-DIMM 64MB) 8-759-668-57 IC HB52D88DC-B6FL (PC 100 SO-DIMM 64MB) A-8066-142-A (F580)... COMPLETE PWB MBX-30 (P650) ASSY (S) 4-648-068-21 LABEL ID (UC)

5-6

214

*1 The pages shown above are on "PCG-F540/F560/F570/F580 SERVICE MANUAL".

NOTEBOOK COMPUTER
This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation.

Sony Corporation
9-872-078-11
Information Technology Company

English 2000F1605-1 Printed in U.S.A. © 2000 Sony Corporation VAIO CUSTOMER LINK (JAPAN)
