About the sub woofer unit Your VAIO Digital Studio® computer is supplied with a sub woofer unit to enhance your system�s sound capability.
Sub woofer unit
Right side Left side Front panel
1
Port The port extends the low frequency response to extend the volume output of the sub woofer unit.
2
Power knob/volume control Rotate the knob clockwise to turn on the sub woofer unit. Volume is controlled by rotating the knob until the desired volume is reached. Rotate the knob counter-clockwise to turn off the sub woofer unit.
3
Power indicator Light is green, while the power is on.
4
Speaker jack Connection for the speaker cable (RCA plug)*.
5
Sub woofer unit cable Connects the sub woofer unit to the computer�s headphones jack.
6
AC power cord Connects the sub woofer unit to a grounded AC wall outlet or power strip.
* See the next section, �Connecting the computer, speakers, and sub woofer unit� for details on connecting the speakers to the sub woofer unit.
