SECTION 2 DISASSEMBLY
2-1. FLOWCHART

ARM REAR COVER P2-1

ARM FRONT COVER P2-2

REAR COVER P2-3

INVERTER UNIT P2-3

LCD ASS'Y (S) P2-4

LEX-23 BOARD P2-4

IFX-105 BOARD P2-5

� P X-X means pages that appears in this manual.

2-2. ARM REAR COVER
4 Three claws 4 Five claws 4 Five claws

5 VAIO rear cover 1 Slant the LCD ass'y (S) in the direction of arrow A.

A

3 Arm rear cover

2 Four claws

6 Four screws +PS (3 � 5)

Confidential
2-1 PCVA-15XD2 (UC)
