PICTURE ADJUSTMENTS
This device has five types of picture quality settings in memory. You can choose one from them or set the picture quality you desire and store it in memory.

RECALL THE DESIRED SETTINGS

1 2

Press MENU and select PICTURE by using the | or \ button and then pressing « button. (Refer to page 26.) Select MODE in the same way.
cc
P I C T UR E MOD E : S T D C ON T R A S T B LA CK L EV EL C OL OR T INT S HA R PN E S S
SELECT SET

0 0 0 0 0
SET MENU END

3

Select the desired setting.

MOD E :

STD REF THEATER GAME USER PRO
SELECT SET SET MENU END

NOTES on GAME mode setting: � We do not recommend the use of the Monitor for video games, still pictures due to the potential damage to the CRTs*. In the event a consumer needs to use these devices for a short period of time, the GAME mode will minimize potential damage to the CRTs* by lowering the relative contrast. � All signals output from the Projection Monitor will be unaffected. Only the original output signal is sent through the output jacks. *CRT: Cathode-ray tube

STD .................... Sets standard picture quality. REF THEATER .... This mode reproduces film material just like a real film image. By cutting video enhancement circuits, the picture becomes more natural and looks filmlike. GAME ................ Lowers the relative contrast of TV game images to minimize discomfort to the eyes. This will minimize bad effects such as discolored spots or stains on the CRT of the Monitor. USER ................. Calls up the picture quality the user has set. See page 53 for on explanation of different picture qualities. PRO .................... In this mode, you can finely adjust the picture quality to your taste.

4

After setting, press MENU to turn the menu off.

52
