Adjust the level of the selected channel as desired.
3
Repeat the above steps each channel level.
and
to adjust
or
DOWN UP
Adjusting the Dolby Pro Logic IIx / Dolby Pro Logic II Music parameters
� When selecting either the Dolby Pro Logic IIx Music mode or the Dolby Pro Logic II Music mode depending on whether �S/B CH� is set to �None� or not, you can adjust the various surround parameters for optimum surround effect.(Refer to �When selecting the SPEAKER CONFIGURATION� on page 49.) � In case of PL IIx MUSIC mode, only when original surround mode is �BYPASS� mode or 2 channel digital signals from Dolby Digital sources, etc. are input, these parameter settings affect the surround effects. Press the DOLBY PL II MUSIC PARAMETER button to select the desired parameter.
1
� Each time this button is pressed, the parameter changes and is displayed for several seconds as follows;
Panorama mode(�PANORAMA�, default value : OFF) This mode extends the front stereo image to include the surround speakers for an exciting �wraparound� effect with side wall imaging. Select �OFF� or �ON�.
or
Center width control(�C-WIDTH�, default value : 0) This adjusts the center image so it may be heard only from the center speaker, only from the left/right speakers as a phantom image, or from all three front speakers to varying degrees. The control can be set in 8 steps from 0 to 7. Dimension control(�DIMENSION�, default value : 0) This gradually adjusts the soundfield either towards the front or towards the rear. The control can be set in 7 steps from -3 to +3.
At the desired parameter, adjust it as desired.
2
or
DOWN UP
3
Repeat the above steps adjust other parameters.
and
to
� If the parameter display disappears, start from the step again.
