Adjusting the Dolby Pro Logic II Music parameters ENGLISH
� When selecting the Dolby Pro Logic II Music mode, you can adjust the various surround parameters for optimum surround effect. � You can also adjust the Dolby Pro Logic II Music parameters with using the buttons on the front panel. (For details, refer to �SETTING UP THE SYSTEM ON FRONT PANEL� on page 43.) Press the PL II MUSIC PARAMETER button to select the desired parameter.
1
PL II PARA.
� Each time this button is pressed, the parameter changes and is displayed for several seconds as follows; Panorama mode(�PANO�, default value: OFF) This mode extends the front stereo image to include the surround speakers for an exciting �wraparound� effect with side wall imaging. Select �OFF� or �ON�. Center width control(�C-WID�, default value: 0) This adjusts the center image so it may be heard only from the center speaker, only from the left/right speakers as a phantom image, or from all three front speakers to varying degrees. The control can be set in 8 steps from 0 to 7. Dimension control(�DIMEN�, default value: 0) This gradually adjusts the soundfield either towards the front or towards the rear. The control can be set in 7 steps from -4 to +2. While displaying the desired parameter, adjust it as desired. Repeat the above steps 1 and 2 to adjust other parameters.
2
3
ADJUST UP(>), DOWN(<)
� If the parameter display disappears, start from the step 1 again.
29
|
|
|
> |
|
