RDC-7UPG2 EXPLODED VIEW
Indicated only the parts which are an addition and change from RDC-7 with the model change to RDC-7UPG2. Please refer to RDC-7 service manual (No.3653 printed matter only) about the other parts. 1 DOOR and LABEL
The position to stick
UPGRADED
Center of DOOR
AV Controller RDC-7
2 1
2 Label on the Top cover
3
PARTS LIST
REF NO. 1 2 3 NAME DOOR LABEL LABEL DESCRIPTION --UPGS --PARTS NO. 28148512 29363154 29363164 QT'Y 1 1 1
