SONY RMTP504
Instrukcja Obsługi

Adjusting the surround parameters

Adjusting the speaker levels

1

Touch SURR EDIT on the SOUND FIELD screen. The SURROUND screen appears.

1

Touch LEVEL EDIT on the SOUND FIELD screen. The LEVEL screen appears.

Operation

2 3 4

Use the JOG DIAL or touch 4 or $ to scroll through the list. Scroll the JOG DIAL to select an item or touch the aspect you want to adjust. Touch value. or to adjust to the desired

2 3 4 5 6

Use the JOG DIAL or touch 4 or $ to scroll through the list. Scroll the JOG DIAL to select an item or touch the item you want to adjust. Touch or to adjust.

SURROUND EFFECT: Higher values increase the �presence� of the surround effect. WALL TYPE: Use to simulate different sonic environments. REVERB TIME: Use to control the spacing of the early reflections to simulate a larger or smaller room. SCREEN DEPTH: Use to control the extent to which the sound appears to be coming from within the screen. VIRTUAL SPEAKERS: Use to set whether to use the virtual speakers or not. Tone quality adjustments: Use these parameters to adjust the overall sound quality of the selected sound field.

Repeat steps 2 through 4 when there is more than one item that you wish to adjust. Touch EXIT when adjustment is finished.

To adjust the speaker balance
Use TEST TONE to listen to the levels output from each speaker. AUTO outputs the test tone to each speaker in order. You can also select individual speakers to output the test tone. Adjust your speaker levels so that the test tone is output at the same level from all speakers.

Notes
� Items that cannot be adjusted due to the current speaker settings or sound field mode are grayed out. � If the alarm sounds, or all items appear to be grayed out, touch RELOAD.

5 6

Repeat steps 2 through 4 when there is more than one aspect that you wish to adjust. Touch EXIT when adjustment is finished.

Notes
� Items that cannot be adjusted due to the current speaker settings or sound field mode are grayed out. � If the alarm sounds, or all items appear to be grayed out, touch RELOAD.

21
