!¶ Attach the bracket to the heatsink with two screws.
bracket heatsink
MAIN board
!� Insert two connectors (CN601, 603) into the connectors (CN301, 911) on the MAIN board.
!ª Connect the fan motor lead wire to MAIN board connector (CN301).
chassis
!§ Insert an insulation sheet between chassis and MAIN board.
@¡ Connect the flat wire to DISPLAY board connector (CN503). @º Connect the power SW lead wire to STANDBY board connector (CN907). @£ Push the power SW.
@� Connect the MAIN board and chassis with two clip wires.
