SKR-L500.fm Page 2 Tuesday, October 4, 2005 2:15 PM
Package Contents
� SKR-L500: Surround back speaker � Speaker cable, 9 m (brown) � Cork spacers, 4 pcs.
Wall Mounting
The speaker can easily be wall mounted by using the keyhole slots. To prevent the speaker from vibrating against the wall, attach four of the supplied cork spacers to the rear of the speaker.
SKR-L500 SKR-L500
Placement
â� Mounting vertically To mount the speaker vertically, use the two keyhole slots shown to hang the speaker on two screws that are securely screwed into the wall.
Cork spacer
Keyhole slot for wall mounting
SKR-L500: Surround back speaker This speaker enhances the realism of surround sound and improve sound localization behind the listener. Position it behind the listener about 2�3 feet (60� 100 cm) above ear level. � The speaker cabinet is sensitive to extreme temperatures and humidity, do not put it in locations subject to direct sunlight or in humid places, such as near an air conditioner, humidi�er, bathroom, or kitchen. � Do not put water or other liquids close to the speaker. If liquid is spilled over the speaker, the drive units may be damaged. � As explained in this manual, mount the speaker on a wall, or on the optional stands/brackets, otherwise, it may fall, causing personal injury or damage to the speaker.
â� Mounting horizontally To mount the speaker horizontally, use the two keyhole slots shown to hang the speaker on two screws that are securely screwed into the wall.
Keyhole slot for wall mounting
Cork spacers
Using Cork Spacers with the Speaker
We recommend using the supplied cork spacers to achieve the best possible sound from your speaker. The cork spacers prevent the speaker from moving, providing a more stable setup.
Cork spacers
The plaque of each speaker rotates so that you can position the speaker upside down. Caution: A mounting screw�s ability to support a speaker depends on how well it�s anchored to the wall. If you have hollow walls, screw each mounting screw into a stud. If there are no studs, or the walls are solid, use suitable wall anchors. Use screws with a head diameter of 9.5 mm or less and a shank diameter of 4 mm or less. With hollow walls, use a cable/pipe detector to check for any power cables or water pipes before making any holes. Leave a gap of 5 mm between the wall and the base of the screw head, as shown. (We recommend that you consult a home installation professional.)
Wall
Bottom of the SKR-L500
5 mm
2
|
|
|
> |
|
