SLV-D300P

6. ALIGNMENT AND ADJUSTMENTS
6-1 VCR ADJUSTMENT
6-1-1 Reference
1) X-Point (Tracking center) adjustment, �Head switching adjustment� and �NVRAM option setting� can be adjusted with remote control. 2) When replacing the Main PCB Micom (IC601) and NVRAM (IC603 ; EEPROM) be sure to adjust the �Head switching adjustment� and �NVRAM option setting�. 3) When replacing the cylinder ass�y, be sure to adjust the �X-Point� and �Head switching adjustment�. 4) How to adjustment. - Intermittently short-circuit the Test Point on Main PCB with pincers to the adjustment mode. - If the corresponding adjustment button is pressed, the adjustment is performed automatically. - If the adjustment is completed, be sure to turn the power off.
6-1-1(a) Location of adjustment button of remote control

X-Point (Tracking Center) Adjustment ; NVRAM Option Setting ; Head Switching Adjustment ;

Fig. 6-1

6-1
