SPECIFICATIONS
System
Channel coverage SLV-SE350K, SE500K/R, SE600N, SE700N/K/R, SE800N/K: PAL (B/G, D/K) VHF E2 to E12, R1 to R12 UHF E21 to E69, R21 to R69 CATV S1 to S41, S01 to S05 SLV-SE600A/E, SX600E, SE650D, SE700D1/D2/E1/E2, SX700D/E, SE800D1/D2/E, SX800D: PAL (B/G) VHF E2 to E12 VHF Italian channel A to H UHF E21 to E69 CATV S01 to S05, S1 to S20 HYPER S21 to S41 SLV-SE600B, SE700B, SX700B, SE800B: SECAM (L) VHF F2 to F12 UHF F21 to F69 CATV B to Q HYPER S21 to S41 PAL (B/G) VHF E2 to E12 VHF Italian channel A to H UHF E21 to E69 CATV S01 to S05, S1 to S20 HYPER S21 to S41 SLV-SE700G/I, SE800G: PAL (I) VHF IA to IJ, SA10 to SA13 (SLV-SE700I) UHF B21 to B69 CATV S01 to S05, S1 to S20 (SLV-SE700I) HYPER S21 to S41 (SLV-SE700I)
SAFETY CHECK-OUT
After correcting the original service problem, perform the following safety checks before releasing the set to the customer: 1. Check the area of your repair for unsoldered or poorly-soldered connections. Check the entire board surface for solder splashes and bridges. 2. Check the interboard wiring to ensure that no wires are �pinched� or contact high-wattage resistors. 3. Look for unauthorized replacement parts, particularly transistors, that were installed during a previous repair. Point them out to the customer and recommend their replacement.
SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
4. Look for parts which, though functioning, show obvious signs of deterioration. Point them out to the customer and recommend their replacement. 5. Check the B+ voltage to see it is at the values specified.
