1. EXPLODED VIEWS
1-1. OVERALL SECTION
ns : not supplied NOTE: � -XX, -X mean standardized parts, so they may have some differences from the original one. � Items marked �*� are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. � The mechanical parts with no reference number in the exploded views are not supplied.
(Note1) When putting grease the O ring (Ref. No. 22) and main packing (Ref. No. 21), always use the grease of the blue tube of the accessory. When using the grease of the yellow tube and the grease of the other Inc., it hurts a cabinet packing and it causes the O ring, main packing. Note : The marked �0� are parts in relation to waterproof. Replace these components with Sony parts. Be sure to check up waterproof after repair. Note : La 0 marquée sont des pièces par rapport
1 8 27 7 6 10 10 9 11 12
à imperméable à l� eau. Ne les remplacer que par une pièce portant le numéro spécifié. Soyez sûr de vérifier vers le haut d� imperméable à l� eau après la réparation.
26
ns
5 25 23 24
3
13 15 4 2 17 14 18 19 1 20 1 16
22
(Note1)
1
ns
1
28 14
ns ns
29
Ref. No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 Part No. 2-342-952-01 2-591-438-01 2-591-418-01 2-657-724-01 2-668-091-01 2-657-726-01 2-659-734-01 2-657-725-01 2-657-728-01 2-591-425-01 2-657-729-01 2-638-625-01 2-591-432-01 2-591-431-01 2-591-428-01 Description
21
(Note1)
Ref. No. 16 17 18 19 20 0 21 0 22 23 24 25 26 27 28 29 Part No. 2-656-801-01 2-591-430-01 2-657-737-01 2-657-738-01 2-657-736-01 2-657-740-01 2-591-447-01 2-657-735-01 2-657-739-01 2-657-733-01 2-657-734-01 2-657-789-01 2-638-612-01 A-1151-690-A Description RETAINER, BUCKLE SLIDER SPRING, BUCKLE SLIDER MODE, SLIDER MODE, CUSHION MODE, CRANK PACKING, MAIN (Note1) O RING (P4) (Note1) KNOB, MODE TAPE (R), DOUBLE STICK BUTTON (R), CONTROL COVER (R), BUTTON LABEL, CAUTION LABEL, BUCKLE RELEASE OVERALL ASSY, MAIN
SCREW (1.7X4 #0-1), TP RETAINER, LENS WINDOW GLASS, LENS WINDOW PACKING, LENS WINDOW SHEET, REFLECTION PREVENTION BUTTON (F), CONTROL BUTTON, SHUTTER COVER (F), BUTTON LEVER (A), BUTTON CUSHION, BUTTON LEVER (B), BUTTON SHEET, AF LIGHT INTERCEPTION CUSHION, SIDE CUSHION (FR) SLIDER, BUCKLE
SPK-THC
�2�
|
|
|
> |
|
