The change parts are the following.Other parts are the same. SR8300 : PARTS LIST
POS. NO. VERS. COLOR 001B /N1B/S1B 001B /N1G/S1G 001B /U1B 001B /U1G 009G 010G 001S 001T /N 001T /S 001T /U PART NO. (FOR EUR) 343J248210 343J248310 DESCRIPTION PART NO. (MJI) 343J248210 343J248310 343J248220 343J248320 03AJ057110 03AJ057110 343J801110 343J851320 343J851360 343J851260
FRONT AL PANEL (SR8300 BL) FRONT AL PANEL (SR8300 GL) FRONT AL PANEL (SR8300 BL) U FRONT AL PANEL (SR8300 GL) U 03AJ057110 LEGS 03AJ057110 LEGS 343J801110 PACKING CASE (SR8300) 343J851320 USER GUIDE SR8300 N USER GUIDE SR8300 S USER GUIDE SR8300 U
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9300 / PS9200A : PARTS LIST
POS. NO. VERS. COLOR 001B /F 001B /N1B/S1B 001B /N1G/S1G 001B /U1B 001B /U1G 003B /F 009G 010G 001T /N 001T /S 001T /U Z011 /F 001S /N/S/U PART NO. (FOR EUR) 344J248210 344J248310 DESCRIPTION FRONT AL PANEL (PS9200 GL)V2 FRONT AL PANEL (SR9300 BL) FRONT AL PANEL (SR9300 GL) FRONT AL PANEL (SR9300 BL) U FRONT AL PANEL (SR9300 GL) U BADGE VERSION 2 LEGS LEGS USER GUIDE SR9300 N USER GUIDE SR9300 S USER GUIDE SR9300 U MAINS CORD DC-302-J 125V 12A PACKING CASE (SR9300) PART NO. (MJI) 344J248340 344J248210 344J248310 344J248220 344J248320 318J251020 03AJ057110 03AJ057110 344J851320 344J851360 344J851260 ZC01802080 344J801110
03AJ057110 03AJ057110 344J851320
nsp
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SERVICE TOOL
Updated of the CPU and DSP DISC ...........................*SR9300CDR REMARK: The disc is used when QU01 and Q671 are replaced. No software is in the IC's when replaced. Refer the service manual for SR9200/SR8200/PS9200 (344J855010) to upload software. The procedure to upload is the same to the SR9200/SR8200/PS9200. However the software is NOT the same to the SR9200/SR8200/PS9200. NEVER write the software to SR9200/SR8200/PS9200. It causes breakdown. So be careful to use this disc to upload.
|
|
|
> |
|
