EXPLODED VIEW AND PARTS LIST
NOTE: � -XX and -X mean standardized parts, so they may have some difference from the original one. � Items marked �*� are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. � The mechanical parts with no reference number in the exploded views are not supplied.

11
SP1

12 11
C901 R901

8 7 9

10

L-CH
6 2

12

2

2

7

SP2

14 2 13 15

2 2
not supplied

23

16 18 17 19

1

14
not supplied

23 16
not supplied

21 20
Remark

23
Ref. No. 16 17 18 19 20 21 23 25 26 27 C901 R901 SP1 SP2 Part No. 4-229-150-01 4-229-160-01 4-229-148-01 4-229-352-01 1-960-567-11 4-229-151-01 4-229-154-01 4-229-163-01 4-229-164-01 4-229-165-01 1-135-903-11 1-216-375-11 1-529-746-11 1-529-745-11

16

not supplied

Ref. No. 1 1 2 6 6 7 8 9 10 11 12 13 13 14 15

Part No. X-4953-048-1 X-4953-049-1 4-229-158-01 4-229-142-01 4-229-168-01 4-229-157-01 4-229-161-01 4-229-353-01 4-229-152-01 4-229-153-01 7-685-547-14 4-229-141-01 4-229-167-01 7-685-547-19 7-685-650-79

Description SPK PANEL (R) ASSY SPK PANEL (L) ASSY SP. FRONT CUSHION (A) SPK PANEL (L) SPK PANEL (R) SP. SEAL SP PANEL WEIGHT SCREW 3X8 SPK SPACER TWEETER HOLDER SCREW +BTP 3X10 TYPE2 N-S SPK CABINET (L) SPK CABINET (R) SCREW +BTP 3X10 TYPE2 N-S SCREW +BTP 3X16 TYPE2 N-S

Remark

Description SPK RUBBER SP EARTH LUG L SP. HOLDER SCREW 3X10 HARNESS SPK. WIRE BUSHING SP. SEAL SP. DAMPER (A) SP. DAMPER (B) SOUND ABSORBER ELECT 2.2uF METAL OXIDE 3.3 SPEAKER TWEETER SPEAKER WOOFER

100V 2W

9-929-064-11

Sony Corporation
Home Audio Division Company

2000B051682-1 Printed in Japan C 2000. 2 Published by Quality Assurance Dept.
