EXPLODED VIEW AND PARTS LIST
NOTE: � Items marked by asterisk ("*") are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.

3

SP2

2 2 1
SP1

2

Ref. No. 1 2 3 SP1 SP2

Part No. X-4950-949-1 4-874-614-11 A-4411-418-A 1-529-255-11 1-529-254-11

Description FRAME ASSY, GRILLE SCREW (4) (3.5 � 14), TAPPING CABINET ASSY, SPEAKER SPEAKER (16 cm) (WOOFER) SPEAKER (2 cm) (TWEETER)

Remarks

Ref. No.

Part No.

Description

Remarks

ACCESSORIES & PACKING MATERIALS ******************************** 1-769-433-22 CORD, SPEAKER 3-866-213-11 MANUAL, INSTRUCTION (ENGLISH/FRENCH/SPANISH/ PORTUGUESE/CHINESE)
