� REMOVAL OF ANODE-CAP
NOTE: Short circuit the anode of the picture tube and the anode cap to the metal chassis, CRT shield or carbon painted on the CRT, after removing the anode.
� REMOVING PROCEDURES
b
c
a
Anode Button
1 Turn up one side of the rubber cap in the direction indicated by the arrow a.
2 Using a thumb pull up the rubber cap firmly in the direction indicated by the arrow b.
� HOW TO HANDLE AN ANODE-CAP
1 Don�t hurt the surface of anode-caps with shartp shaped material! 2 Don�t press the rubber hardly not to hurt inside of anodecaps! A material fitting called as shatter-hook terminal is built in the rubber. 3 Don�t turn the foot of rubber over hardly! The shatter-hook terminal will stick out or hurt the rubber.
3 When one side of the rubber cap is separated from the anode button, the anode-cap can be removed by turning up the rubber cap and pulling up it in the direction of the arrow c.
