SONY SSRC370
Instrukcja Serwisowa

SS-CT370/RC370/RS370
SERVICE MANUAL
Ver 1.0 2002. 04

US Model Canadian Model Australian Model

Photo : SS-CT370

� SS-CT370/RC370/RS370 are speaker systems in MHC-GS300AV.

Photo : SS-RS370

� SS-RC370 is composed of following models.

EXPLODED VIEW AND PARTS LIST

COMPONENT MODEL NAME
SS-RC370 SS-CT370 (CENTER SPEAKER SYSTEM) SS-RS370 (REAR SPEAKER SYSTEM)

1

SPECIFICATIONS
Rear speaker SS-RS370 Speaker system Speaker units Full-range: Nominal impedance Dimensions (w/h/d) Mass Center speaker SS-CT370 Speaker system Speaker units Full-range: Nominal impedance Dimensions (w/h/d) Mass

2

1-way, 1-unit, bass-reflex type 8 cm, cone type 6 ohms Approx. 215 � 120 � 128 mm Approx. 0.8 kg net per speaker

Ref. No.
1-way, 1-unit, bass-reflex type magnetically shielded 8 cm, cone type 6 ohms Approx. 280 � 120 � 127 mm Approx. 1.0 kg net per speaker

Part No.

Description

Remarks

1 1

A-4330-583-A OVERALL ASSY (SS-CT370) A-4330-582-A OVERALL ASSY (SS-RS370)

SPEAKER SYSTEM
9-873-989-01
2002D1600-1 © 2002.04

Sony Corporation
Home Audio Company Published by Sony Engineering Corporation
