x
SW
S.W. XXX (SUB WOOFER)
5: Setting up the speakers
You can use the SET UP menu to set the size, distance and location of the speakers connected to this receiver.
(Sub woofer selection)
� YES If you connect a sub woofer, select �YES�. � NO If you did not connect a sub woofer, select �NO�. The front speakers are automatically set to �LARGE� and you cannot change this setting. This activates the bass redirection circuitry and outputs the LFE signals from other speakers. � In order to take full advantage of the Dolby Digital bass redirection circuitry, we recommend that you set the cut off frequency on the sub woofer as high as possible.
x XXXXX (FRONT) (Front speakers size)
L R
1 2 3
Press ?/1 to turn on the receiver. Press MAIN MENU repeatedly to select � SET UP �. Press or repeatedly to select the parameter you want to adjust.
For details, see �Speaker setup parameters� below.
Note
Some speaker setup items may appear dimmed in the display. This means that they have been adjusted automatically due to other speaker settings or may not be adjustable.
� LARGE If you connect large speakers that will effectively reproduce bass frequencies, select �LARGE�. Normally, select �LARGE�. � SMALL If the sound is distorted, or you feel a lack of surround effects when using multi channel surround sound, select �SMALL� to activate the bass redirection circuitry and output the front channel bass frequencies from the sub woofer. When the front speakers are set to �SMALL�, the center, surround and surround back speakers are also automatically set to �SMALL� (unless previously set to �NO�).
x XXXXX (CENTER) (Center speaker size)
C
4
Press + or � repeatedly to select the setting you want.
The setting is entered automatically.
Note
Press ENTER on the receiver if you select the setting for �SP. PAT. X �X�.
5
Repeat steps 3 and 4 until you have set all of the items that follow.
Speaker setup parameters
The initial settings are underlined.
x XXXX SET (Speaker easy setup)
� EASY If you want to set up your speakers automatically, select �EASY SET�. You can select a pre-defined speaker pattern (see the supplied �Easy Setup Guide�). � NORM If you want to adjust the settings of each speaker manually, select �NORM SET�.
x SP. PAT. X �X (Speaker setup pattern)
� LARGE If you connect a large speaker that will effectively reproduce bass frequencies, select �LARGE�. Normally, select �LARGE�. However, if the front speakers are set to �SMALL�, you cannot set the center speaker to �LARGE�. � SMALL If the sound is distorted, or you feel a lack of surround effects when using multi channel surround sound, select �SMALL� to activate the bass redirection circuitry and output the center channel bass frequencies from the front speakers (if set to �LARGE�) or sub woofer.a)
When you select �EASY SET�, select the speaker setup pattern. Press + or � repeatedly to select the speaker setup pattern and press ENTER to enter the selection. Check your speaker pattern using the supplied �Easy Setup Guide�. 18GB
