PIONEER TS-CX9/EW
Instrukcja Serwisowa

TS-CX9

3. EXPLODED VIEWS AND PARTS LIST
NOTES:

� Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. � The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. � Screws adjacent to mark on the product are used for disassembly.

3.1 MAIN UNIT
A : Adhesion portion
1

� MAIN UNIT PARTS LIST
Mark No.
NSP NSP NSP NSP NSP NSP NSP NSP NSP NSP NSP NSP 1 2 3 4 5 6 7 8 9 10 11 12 13 14

Description
Main Unit Speaker Mesh Case Case Lock Tie Cord Rubber Bush Packing Cushion Sound Absorbent Sound Absorbent Cushion Screw

Part No.

Remark
�1 �1 �1 �1 �1 �1 �1 �1 �1 �1 �1 �1 �1 �2

3 14

2

TXA1335 66-173AM TLL1437 TLM1501 TLM1500 CNV-754 TDC2395 TEB1032 TED1540 TED1549 TED1561 TED1562 TED1563 BPZ40P200FZK

9

12 11

4 Round

A

10

A A
Round

A A

A

13 5 7 6 8

2
