Remote controller
TX-SR601
INPUT SELECTOR buttons Press to select an input source. Same as the input selector buttons on the front panel of the TXSR701/701E/601/601E. The input source for each button is given here. DVD:DVD, CD:CD, V1:VIDEO1, V2:VIDEO2, V3:VIDEO3, V4:VIDEO4, V5:VIDEO5 (not used with the TXSR701/701E/601/601E), TAP:TAPE, TUN:FM/AM, PH:PHONO (not used with the TX-SR601/601E). Numeric key/Listening mode, SP A, SP B, CINE FLTR, DISPLAY, DIMMER buttons 1 to 9, +10, --/---, 0: For entering the number of a track. PURE A: TX-SR601/601E: Not used with the TX-SR601/601E. TX-SR701/701E: Press to select the Pure Audio mode. DIRECT, STEREO, SURR, ALL ST, DSP (TX-SR601/601E), DSP / (TX-SR701/701E), THX (TX-SR701/701E): You can select a listening mode. Note: During playback of a multichannel source, press the DIRECT button to turn off the tone control and the SURR button to turn on the tone control. SP A, SP B: Not used with the TX-SR601/601E. CINE FLTR (TX-SR601/601E): Depending on the listening mode, you can turn the CinemaFILTER function on or off. Re-EQ (TX-SR701/701E): Depending on the listening mode, you can turn the Re-EQ function on or off. DISPLAY: For changing the display in the front display. DIMMER: Adjusts the display brightness. There are three settings available: normal, dark, and very dark. LIGHT button (RC-533M only) Press to turn on and off the lights in the buttons of the remote controller. SETUP button Press to display the Setup Menu on the TV screen and in the display. Press again to exit the menu. / / / , ENTER button When in the Setup Menu, press the upper and lower arrow buttons to select an item, press the right and left arrow buttons to select parameter values or modes, and press the ENTER button to advance to the next item. VOL button Press to adjust the volume. TEST/MENU button This button is used to set the speaker output levels. Use this button in conjunction with the LEVEL / and CH SEL buttons to calibrate the speakers levels without entering the Setup Menu. [43] When the DVD mode is selected, press to display the DVD menu (MENU).
MUTING button AUDIO ADJUST button ZONE 2/SEARCH/ENTER button When the DVD mode is selected, press to �nd the speci�c section on a DVD where you want to start playback (SEARCH). When in the RCVR mode, press to perform operations on the remote zone (ZONE 2). When in the MD mode, press to enter the selected song (ENTER).
Page 10
|
|
|
> |
|
