NOTE : � -XX, -X mean standardized parts, so they may have some difference from the original one. � Items marked � * �are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. � The mechanical parts with no reference number in the exploded views are not supplied.
ns
3 13 14 15 16 12 11 7
4 5
6 2
9
8
10
1 10
Ref. No. 1 2 3 4 5 6 7 8 9 10 Part No. 3-972-158-01 3-972-005-01 3-972-004-01 3-972-003-01 3-972-006-01 Description BAG, TRIPOD KNOB(WASHER), PAN BAR LEVER(SCREW TO), SHOE SHOE, QUICK STOPPER, TILT Ref. No. 11 12 13 14 15 16 Part No. 3-056-411-01 1-828-908-13 3-088-743-01 3-088-742-01 3-088-744-01 Description HOLDER, HAND CORD, CONNECTION SPRING, 368 LEVER RETAINER, 368 SPRING RETAINER, 262 LEVER
3-972-007-01 STOPPER, PAN A-7007-969-A BAR BLOCK ASSY, PAN 3-054-902-01 TRIPOD(MAIN) (WITHOUT 2, 3, 4, 5, 6 ,7 ,9, 10, 11, 13, 14, 15, 16) 3-972-009-01 KNOB, ELEVATOR FIXED 3-972-010-01 RUBBER, FERRULE
3-088-745-01 SHAFT (SP), UH LEG 3-866-291-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH, GERMAN,SPANISH)(US, CND, AEP) 3-866-291-21 MANUAL, INSTRUCTION (DUTCH,SWEDISH, ITALIAN,PORTUGUESE)(US, CND, AEP) 3-866-291-31 MANUAL, INSTRUCTION (RUSSIAN, TRADITIONAL CHINESE,KOREAN, ARABIC)(US, CND, AEP)
