The INPUT SETTING Menu
The INPUT SETTING menu is used to change the settings of the input signal. Unadjustable items, which vary according to the input signal, are not displayed in the menu.
INPUT SETTING INPUT-A DOT PHASE: 8 SIZE H:1 3 4 4 SHIFT H:1 2 3 V: 1 2 3

SCAN CONV (converter)
Converts the signal to display the picture so that it fits the screen size. ON: Displays the picture to fill the 4:3 screen. The picture will lose some clarity. OFF: Displays the picture while matching one pixel of input picture element to that of the LCD. The picture will be clear but the picture size will be smaller.
Note

Input signals and adjustable/setting items
Input signal Item Video or S video N 15k RGB N Component/ RGB RGB Progressive (preset) (not preset) component N Y (except for HDTV, DTV) SIZE SHIFT SCAN CONV N Y N N Y N Y Y N Y Y Y Y Y

DOT PHASE

About the memory function The adjustment data for 48 types of input signals are preset at the factory (preset memory). When a signal is input to the projector, the signal type is automatimally detected and the data for the signal is called from the memory to display an optimum picture. The data can be adjusted in the INPUT SETTING menu and the adjusted data will be saved as user memory. When you save more than 200 user memories, the newest one always overwrites the oldest one. The saved user memory number is displayed in the INPUT SETTING menu as t NO. ss. When an RGB signal other than the preset signals is input to the projector, the memory number is displayed as 0 and the closest option is automatically selected from the preset 48 types of signals.
Notes

1024x768 NO . 2 3 n 20

The function does not work for signals in Memory No. 32 and 33.

DOT PHASE
Adjusts the phase of the LCD panel and the input signal when H FILTER is set to OFF. Adjust the value to obtain the clearest picture.

ASPECT
Sets the aspect ratio of the picture. When inputting 16:9 (squeezed) signal from equipment such as a DVD player, set to 16:9. 4:3: When the picture with ratio 4:3 is input 16:9: When the picture with ratio 16:9 (squeezed) is input
ASPECT H FILTER Y N Y N Y N

Y Y (Only for (Only for lower lower resolution resolution than than SXGA) SXGA) N N Y (UXGA only) Y

SIZE
Adjusts the horizontal size of the picture. As the setting for H increases, the horizontal size of the picture becomes larger, and as the setting decreases, the size becomes smaller. Adjust the setting according to the input signal. Use the B or b key to adjust the horizontal size.

BLANKING

Y (UXGA only) Y Y Y Y (TOP (TOP and (TOP (HDTV, and BOTTOM and DTV BOTTOM only) BOTTOM only) only) only)

H FILTER
Corrects the vertical bands that appear on the picture. The vertical bands may occur when an RGB signal with horizontal resolution of more than 1280 � 1024 pixels is input. In such cases, set to ON. The picture will loose some clarity, but the vertical bands will be reduced. Set to OFF to associate a dot of the input signal with a pixel of the LCD.

Y: Adjustable/can be set N: Not adjustable/cannot be set

SHIFT
Adjusts the position of the picture. H adjusts the horizontal position of the picture, and V adjusts the vertical position. As the setting for H increases, the picture moves to the right, and as the setting decreases, it moves to the left. As the setting for V increases, the picture moves up, and as the setting decreases, it moves down. Use the B or b key to adjust the horizontal position and the V or v key for the vertical position.

INPUT MEMORY No.
The upper number indicates the memory number of the current input signal. The lower number indicates the user memory number.
INPUT SETTING INPUT-A DOT PHASE: 8 SIZE H:1 0 4 8 SHIFT H:1 2 3 V: 1 2 3

� When an RGB signal is input with sync on Green including external sync, the picture tone may be greenish. In this case, disconnect the external sync signal. � When an HDTV 1035/60i signal is input, the picture will appear smaller. Adjust SIZE, SHIFT and BLANKING referring to the following levels as a standard. SIZE H: 1479 SHIFT H: 321 V: 41 BLANKING TOP: 167 BOTTOM: 167 RIGHT: 27 LEFT: 27 � If SCAN CONV is set to ON when a signal in Memory No. 34 �38 is input, the picture will appear widened. Adjust SIZE and SHIFT, referring to the following levels as a standard.
Memory No. SIZE SHIFT H V 34 1590 181 18 35 1575 170 32 36 1590 182 36 37 1582 146 36 38 1620 154 42

BLANKING
Adjusts if excess signals are seen with the picture, or the whole picture is not seen clearly. Select BLANKING, then press the ENTER key to display the blanking adjustment screen. Use the V or v key to select the part to be adjusted (TOP, BOTOM, RIGHT or LEFT), and the B or b key to adjust.

Type of input signal
1024x768 NO . 1 n 23
