Setting up the receiver
06
100Hz
150Hz
Front speaker distance setting
� Default setting: 10 ft. Sets the distance from the front speakers to the listening position. � Use � or � to set the distance of the front speakers from the main listening position (within a 30 foot range).
200Hz
100 Hz Sends bass frequencies below 100 Hz to the subwoofer (or L speakers). 150 Hz Sends bass frequencies below 150 Hz to the subwoofer (or L speakers). 200 Hz Sends bass frequencies below 200 Hz to the subwoofer (or L speakers).
Center speaker distance setting
� Default setting: 10 ft. The center speaker is normally placed directly in the front of the listening room and closer to the listening position than the front speakers. This means that the sound from the center speaker will be heard before the front speakers. To prevent this, set the center speaker distance setting to delay the sound from the center speaker so that the sound from the front and center speakers will be heard at the same time. � Use � or � to set the distance of the center speaker from the main listening position (within a 30 foot range).
If all speakers (front, center, and surround) are set to L, the crossover frequency can�t be set because there are no S speakers ( appears in the display).
LFE attenuator setting
� Default setting: 0 dB Dolby Digital and DTS audio sources include ultra-low bass tones. Set the LFE attenuator as necessary to prevent the ultra-low bass tones from distorting the sound from the speakers. � Use � or � to set the attenuation level (0 dB, 10 dB or dB(�)). When C is selected in the speaker setting, the center distance can�t be set.
Surround speaker distance setting
� Default setting: 10 ft. Like the center speaker, you should set the distance of the surround speakers accurately to hear sounds coming from both front and surround speakers at the same time. � Use � or � to set the distance of the surround speakers from the main listening position (within a 30 foot range).
0 dB
10 dB
� (displays
)
When � is selected ( appears in the display), LFE is not available.
