SONY WMFS55J
Instrukcja Serwisowa

SECTION 5 EXPLODED VIEWS
NOTE : � -XX, -X mean standardized parts, so they may have some difference from the original one. � Items marked � * �are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. � The mechanical parts with no reference number in the exploded views are not supplied.

WM-FS555/FS555J/FS556

� Hardware (# mark) list and accessories and packing materials are given in the last of this parts list. � Abbreviation CND :Canadian

5-1. CASSETTE LID SECTION 9 6 8

11

16

14 7 5 6 10 12 15 13 4 1 12

2 3

1

Ref. No. 1 2 3 4 5 6 7 8 9

Part No. 3-224-946-01 3-235-969-01 3-235-980-01 3-318-203-62 X-3369-989-4 3-386-373-01 3-235-966-01 3-235-984-01 3-235-976-01

Description SHAFT (BUCKLE) BUCKLE PACKING (CABINET) SCREW (B1.7X4), TAPPING ARM ASSY SCREW, TAPPING LID (CASSETTE) SHEET (CASSETTE), ADHESIVE RUBBER

Remark

Ref. No. 10 11 12 13 14 15 16

Part No.

Description

Remark

3-224-941-11 PACKING (MD.RVS) 3-224-951-01 4-225-316-13 3-224-945-11 3-235-981-01 3-895-823-41 SHEET (MD), ADHESIVE ROLLER SHAFT (ROLLER) BRACKET SCREW (B1.4X4), TAPPING

7-624-101-04 STOP RING 1.2 (E TYPE)
