1 SPECIFICATIONS
General
System ......................................................................SACD and CD Power supply ........................................................AC 120 V, 60 Hz Power consumption ..............................................................40 W Weight................................................................25 kg (55-1/16 lb) External dimensions (W x H x D) ..................442 x 153 x 353 mm (17-3/8" x 6" x 13-7/8") Operating temperature ................................................+5�C - +35�C Operating humidity..........................5% to 85% (no condensation) Storage temperature ................................................�20�C - +55�C

Accessories
Power cord x 1 Remote Control Unit (RC-941) x 1 Batteries (AA, R6, SUM-3) x 2 Screwdriver x 1 Felt x 3 Warranty card x 1 Owner�s manual x 1

� Design and specifications are subject to change without notice. � Weight and dimensions are approximate.

Audio output (Analog Audio)
Jacks ......................................................XLR jacks (2 channel) x 1 RCA jacks (5.1 channel) x 1 Maximum Output level (1 kHz, full scale) ..............2.5 Vrms (RCA) 2.3 Vrms (XLR) Nominal Output level (1 kHz, full scale �20dB) ..250 mVrms (RCA) 230 mVrms (XLR) Frequency response ......................................5Hz - 58 kHz (SACD) Signal-to-Noise Ratio (S/N)..........................112 dB (SACD, 1 kHz) Dynamic range ............................................106 dB (SACD, 1 kHz) Total harmonic distortion............................0.001% (SACD, 1 kHz)

Audio output (Digital Audio)
OPTICAL ..........................Optical digital jack x 1, �15 to �21 dBm COAXIAL ............................................RCA jack x 1, 0.5 Vp-p/75 �
153mm 332mm

Word Synchronization input format
Jack ........................................................................................BNC Input level ................................................................4.5 Vp-p/75 � The main unit can accept and synchronize to the following frequencies received from external devices: 44.1kHz, 88.2kHz, 176.4kHz

353mm

442mm

�2�
