Adjusting the recording level
1 Perform the procedure of �Recording� until step 4. ¤
2 Adjust the recording level.
The adjustment range is between -2 ~ +2.
PGM MEMO EDIT AUTO DISC ALL TUNED STEREO RDS EON TA NEWS INFO. TP PTY TOTAL SPACE kHz MHz MAX
SLEEP O.T.T. ECHO P.B.C. EQ. ON MANU.
PROG. MUTE 12
1 6
N.B.
LEVEL ADJUST
O p �
A D J U s T + 1: + 1
2 7
3 8 13 18
11 12 16 17
45 9 10 14 15 19
20
÷ If the recorded sound is too large or distorted, decrease the recording level. If it is too low, increase the recording level.
3 To restart recording
Op�
REC / ARM
Restarting recording
The following procedure allows to re-record sound from the middle of recording. The following procedure assumes the presence of a nonrecorded section of 4 seconds before the recording start position. 1 Press the key during recording.
When the tape is moving 2 way.
1 ¡
O
p
�
When the tape is moving 3 way.
÷ Recording is stopped, the tape is returned to the recording start position, and the deck enters stop mode after leaving a non-recorded section of about 2 seconds after the previous music. ÷ If there is no music recorded before the recording start position, the deck enters stop mode after tape rewinding.
2 Return the recording source component to the position you want to restart recording, and put the source component to pause mode. 3 Press the REC/ARM key twice.
Blinks.
In a few sec., REC/ARM and PAUSE keys light up.
8
REC / ARM
Op�
REC / ARM
PAUSE
REC / ARM
÷ The deck enters record-pause mode after leaving a non-recorded section of about 4 seconds. ÷ In case recording is restarted from the beginning of a tape, feed the leader tape (the non-recordable section at the beginning of each side of tape) manually before starting recording.
