SECTION 4 MECHANICAL ADJUSTMENT
4-1. ELEVATOR HEIGHT ADJUSTMENT This adjustment should be done when replacing the rack assembly on the parts related to it. Procedure: 1. Fit the EV gear assembly after adjusting its slit position as shown in the figure. (When the slit position is out of order after fitting, it can be adjusted finely turning the worm gear of the ELV motor.)
two screws PTT 2 � 4
A

2. Fit the rack assembly putting it in the arrow A direction. At this time insert a spacer (approx. 1 mm thickness) or fit the rack assembly while pushing the EV chassis assembly in the arrow B direction.
rack (110) ass�y screw PTT 2 � 4 EV chassis ass�y

slit

EV gear ass�y

(slit position)

B

Note: When this adjustment is out of order, it doesn�t operate normally and the roaring of the motor can be heard. In this case adjust again.
ELV motor

� 45 �
