1 Insert the rechargeable batteries with the 0 and 9 marks correctly aligned. 2 Connect the AC adaptor. 1 to DC 5~6 V jack 2 to a wall outlet 3 Keep sSTOP/OFF/CHARGE pressed for about 2 seconds to start charging. �C-on� appears and the battery indicator blinks. When charging is completed, �C-OFF� flashes a few times, and battery indicator goes out. After charging, disconnect the AC adaptor.

D

Recharge the batteries when lights. If the unit remains in use after �Lo-bAtt� is displayed and the current operation will stop.

Time to recharge the batteries

lights,

Force charging
When the recharging stops after only few minutes or the batteries cannot be fully recharged, press sSTOP/OFF/CHARGE while pressing PLAY MODE to start force charging. � Do not activate the force charging on the unit when there is no battery inserted or when dry cell batteries were inserted. Doing so may cause malfunction.

To stop charging
Press sSTOP/OFF/CHARGE during charging.

ATTENTION:
The product you have purchased can be powered by nickel cadmium batteries which are recyclable. At the end of their useful life, under various state and local laws, it is illegal to dispose of these batteries into your municipal waste stream. Please call 1-800-289-2492 for information on how to recycle these batteries.

USING ON AC HOUSE CURRENT

E

Connect the supplied AC adaptor in the same way as when recharging the batteries. During operation on AC house current, all of the battery indicators turn off.

BEFORE PLAYBACK
HOLD switch � D
When operating with the main unit, release HOLD on the main unit. � a When operating with the remote control, release HOLD on the remote control. �b When not using the unit, set both HOLD to the hold position. � c Accidentally pressed buttons will not function. If buttons are pressed when the HOLD switch is set to the HOLD position, �HOLd� flashes in the display.

Turning on and off � D
Turning the power on
Press e PLAY/PAUSE. Power is turned on and playback starts.

Note
�Err� appears on the display in the following cases: �When you try to play the unit without a disc in the disc compartment. �When you play a disc placed upside-down or a defective disc.

Turning the power off

F1
OPEN

If no new operations are done within 30 seconds from the end of last operation, the power is turned off automatically. (Auto power off function) � You can turn off the power by pressing sSTOP/OFF/CHARGE before it is automatically turned off.

Standby mode � D
When an operation finishes, the unit goes into standby mode until the auto power off function automatically turns off the power. To enter standby mode, press e PLAY/PAUSE to start playback, then press sSTOP/OFF/CHARGE.

Adjusting the sound

2

3

Volume � E
After setting the VOL control of the main unit to the almost center, then adjust the VOL control of the remote control.

DSL � E
Press DSL for more powerful sound and deeper bass. : Deep bass is emphasized. : Normal sound

Inserting a disc � F
1 Slide the OPEN switch to open the disc compartment. 2 Place a disc in the center with the label side facing up. 3 Close the disc compartment.

G

Pick up the disc, holding its edge, while pressing the pivot gently.

To remove the disc � G Note

� The unit may not play a CD-R/RW disc that is recorded on personal computers or some kinds of CD-R/RW recorders because of differences in recording platforms. � Do not attach any seal or label to either side (the recordable side or the labeled side) of a CD-R/RW disc. It may cause malfunction.
