SECTION 3 ASSEMBLY OF MECHANISM DECK
Note: Follow the assembly procedure in the numerical order given.

HOUSING
5 Fit projection on C part. 2 Install the hanger onto two claws of the housing. 4 Fit claw on B part.

7 Holder the hanger by bending the claw. 1 Install the catch to the hanger.

hanger
6 Fit projection on D part.

3 Put the housing under A part.

housing
C part 8 Hold the hanger by bending the claw.

D part

A part

B part

ARM (SUCTION)

2 Move the arm (suction) in the arrow direction and fit on projection.

projection

1 Fit the arm (suction) on the shaft.
