PIONEER XR-VS500D
Instrukcja Obsługi

3 Controls & Displays

Front panel
1 23 4 56 7 89

31

W2-2001

10 30 29 28 11 27 26
DVD CD
PHONES
DOLBY /DTS

12 13

VIDEO NR

25 24 23 22 21 20 19
1 2 DISC-1/2/3 (page 52) Press to select discs in the player directly. AUDIO MODE (page 78) Press to switch between the preset audio settings (use the JOG dial for smooth adjustment). ZOOM SURROUND (page 80) Press to switch between Zoom Surround modes (use the JOG dial for smooth adjustment). EQUALIZER (page 79) Press to switch between the preset Equalizer settings (use the JOG dial for smooth adjustment). SET Use to enter timer and other settings made with the JOG dial. JOG dial Use to morph between sound settings and when setting the clock or timer. P.BASS (DEMO) (page 80) Press to switch between P.Bass modes (use the JOG dial for smooth adjustment). DISPLAY MODE (page 32, 81) Use to switch the sound level display pattern. 9

14 15 18 1716
VISUAL MODE (page 79) Press to switch between the preset visual settings (use the JOG dial for smooth adjustment). 10 VOLUME UP/DOWN Use to adjust the overall volume. 1 PHONES jack (Headphones) 1 Plug in a pair of headphones to this jack. 12 MONO (page 66) Press to listen to a stereo FM broadcast in mono (sound quality is usually improved). 13 TIMER / CLOCK ADJ (page 32, 84) Use to start setting the clock/timer. 14 Playback/tuning controls 7 ST. MEMORY When playing tapes or discs, press to stop a disc or tape currently playing. When in the tuner mode, press to change from manual tuning to the station presets. ¢ � ¡·+ Use for forward scanning and track skip when playing a disc. Use for forward music search and fast-forward when playing a tape. When listening to the radio, use to select a preset station, or tune manually to a station.

3

4

5 6

7

8

22
En
