7. DISASSEMBLY
Note 1: Do NOT look directly into the pickup lens. The laser beam may cause eye injury. Note 2: Even if the unit shown in the photos and illustrations in this manual may differ from your product, the procedures described here are common.
A

Disassembly
1 Bonnet, Tray Panel

1 1 2 3 4 5 6 7

Remove the bonnet by removing the nine screws. Press the u STANDBY/ON button to turn on the power. Press the h OPEN/CLOSE button to open the tray. Remove the tray panel. Set the test disc. Press the h OPEN/CLOSE button to close the tray. (Test disc is clamped.) Press the u STANDBY/ON button to turn off the power. Pull out the Power cord. Test disc
B

4

3 2 5
Tray panel Tray

25 16

C

D

How to open the tray when the power cannot be on
1. Slide the rack, loading (White) toward the arrow direction by using a minus screwdriver to release the lock. 2. Manually open the tray. NOTE: Please strongly pushing rack, loading (White) to release the lock because the tray doesn't go out easily.

Minus screwdriver
E

Rack, loading (White) Tray open
F

Bottom view

XV-DV575
5 6 7 8
