Operating Pitch Shifter and Reverb
(Example) Pitch-shift the CH3 song by 90%.
1 2 3 4
1 Set the effect selector to PITCH SHIFTER. 2 Set the effect channel selector to CH3.
� The parameter LED 3 lights up. * All the auto BPM counter displays go off.
AUTO BPM COUNTER
REAL AVERAGE
3 Set the parameter value (pitch %) using the parameter knob.
� To check the effect sound, press the effect of the monitor selector. This will enable the effect sound to be monitored using the headphone and booth monitor outputs.
MASTER
1
2
3
4 MIC
PARAMETER
%
4 Turn on the effect switch.
� The effect switch blinks and the effect (pitch shift) is imposed on the master output. Each press will turn on or off the effects. The reverb effects can be produced by operating in the same way.
1/2 3/4 1/1 BEAT 2/1
4/1
Display where CH3 has been pitch-shifted by 90%.
Using the External Effector
(Example) Set the external effect for the CH3 song.
1 Set the effect selector to SEND/RETURN. 2 Set the effect channel selector to CH3.
� The parameter LED 3 lights up.
1 2 3 4
3 Set the parameter of the external effector, etc.
� To check the effect sound, press the effect of the monitor selector. This will enable the effect sound to be monitored using the headphone and booth monitor outputs.
AUTO BPM COUNTER
Displays the channel and BPM selected with the monitor selector.
REAL AVERAGE
4 Turn on the effect switch.
� The effect switch blinks and the effect (external effect) is imposed on the master output. Each press will turn on or off the effects.
MASTER
1
2
3
4 MIC
To use the auto BPM counter while using the external effector, select one channel from CH1 to CH4 of the monitor selector (auto BPM counter selector). � The LED of the channel selected by the auto BPM counter lights up. � The BPM of the song input to the channel will be displayed on the auto BPM counter window (upper window). � Select the BPM display (real-time/average) with the switch button. Real-time display : Displays the measured BPM value for every beat. If it cannot be measured for more than 5 seconds, �� � �� will be displayed. Average display : Measures and displays the average of the BPM values measured every beat. Continues displaying the previous BPM value when the average value could not be measured.
