Arrangement of the flexible cable for the pickup
: Conductive surface Note: Be sure to move the Pickup Assy-S to the innermost perimeter.
A
1 2 3
Fold the flexible cable inward at the position of the reference line. Attach the flexible cable of the pickup to the connector. Fold the flexible cable of the pickup with the backing inward.
7
Pass the flexible cable below the hook, and fold it back. Make sure that the cable does not have any slack
7
Reference line
2
3
1
Hook
B
Backing 97mm ± 2mm
Front Side
Bottom View
8 4
Pass the flexible cable through the hook not allowing any slack. Make sure there is no slack in the cable Reference line
Fold the flexible cable back at the hook. Make sure that the cable is loose Hook
C
8 4
Hook
D
5 6
Fold the flexible cable as indicated in the photo. Hook the part folded in Step 1 to the hook.
9 6
Fold the flexible cable along the hook.
5
9
Reference line Hook Hook
E
Pass the cable below the hook
F
DV-366-S
5 6 7 8
71
|
