SONY DVP-NC650V
Instrukcja Obsługi

DOLBY DIGITAL

Select this when the player is connected to an audio component with a built-in Dolby Digital decoder. If the player is connected to an audio component lacking a built-in Dolby Digital decoder, do not set this. Otherwise, when you play the Dolby Digital sound track, a loud noise (or no sound) will come out from the speakers, affecting your ears or causing the speakers to be damaged.

96kHz/24bit

All types of signals including 96kHz/24bit are output in their original format. However, if the signal is encrypted for copyright protection purposes, the signal is only output as 48kHz/16bit. If a receiver (amplifier) which cannot accept 96kHz is connected to the player, do not set this. Otherwise, a loud noise may come out from the speakers.

xDTS (DVD VIDEO only) Selects if DTS signals are output via the DIGITAL OUT (OPTICAL or COAXIAL) jack.
D-PCM Select this when the player is connected to an audio component lacking a built-in DTS decoder. If you play DTS audio sound tracks, the player outputs stereo signals via the DIGITAL OUT (OPTICAL or COAXIAL) jack. DTS Select this when the player is connected to an audio component having a built-in DTS decoder. If the player is connected to an audio component lacking a built-in DTS decoder, do not set this. Otherwise, when you play the DTS sound track, a loud noise (or no sound) will come out from the speakers, affecting your ears or causing the speakers to be damaged.

Notes
� Even if you set �48kHz/96kHz PCM� in �AUDIO SETUP� to �96kHz/24bit,� the sampling frequency is converted to 48kHz/16bit when a �SURROUND� mode (page 58) is selected. � The analog audio signals from the LINE OUT L/R (AUDIO) 1/2 jacks and 5.1CH OUTPUT jacks are not affected by this setting and keep their original sampling frequency level.

Settings and Adjustments

x48kHz/96kHz PCM (DVD VIDEO only) Selects the sampling frequency of the audio signal to be output via the DIGITAL OUT (OPTICAL or COAXIAL) jack.
48kHz/16bit The audio signals of DVD VIDEOs are always converted to 48kHz/16bit.

85
